Most sold olfactometer worldwide
The popularity of the TO8 is
indisputable: it is the most sold olfactometer worldwide. It meets all
requirements of a dilution device for olfactometric measurements according to
EN 13725. It uses a unique and specially designed dilution system for odour
samples.
The TO8’s main application is to
measure odour concentration, providing a full record of the data obtained, according to EN 13725. The
measurement process is fully automated. It can also be used to assess hedonic
tone or intensity (VDI 3882).
The compact size and
transportability of this model means you can measure onsite in a mobile
laboratory if required – and so keep sample storage time to a minimum.
FACTS:
- Most sold olfactometer worldwide
- Fully automatic, 100 % compliant to EN 13725
- Unique + special designed dilution system
- Software includes project + panel database
- Yes-/No-Method, Intensity + Hedonic Tone
- Fastest analysing time, Fastest setup time
- Mobile & plug and play technology
- Heated dilution system to prevent contamination
- Filter system
- Robust transport box
- Heating system to prevent contamination
- Full version software: Dynamic olfactometry and intensity/ hedonic tone on USB stick
- 5 m compressed air connecting PTFE pipeline
- Compressed air connection (8mm external)
- 50 x 10 l bags
- Proprietary calibration certificate in accordance with ISO 17025
|
Manufacturer |
|
Dimension (L x W x H) a) assembled b) transport size |
|
Weight |
|
Maximum calibration
interval |
|
Warranty |
|
Olfasense GmbH, Germany |
|
a) 650 x 650 x 470 mm b) 650 x 650 x 270 mm |
|
17 kg |
|
12 months (according to EN 13725) |
|
24 months (warranty extension up to 5 years through
servicecontracts possible |
|
Dilution principle |
|
Vent for surplus diluted
odour |
|
Number of panel members working simultaneously |
|
Maximum panel size (software setting) |
|
Analyses time for one
sample |
|
Required air supply |
|
Dilution range |
|
Interval steps |
|
Dilution accuracy |
|
Response / setting time |
|
Required sample volume |
|
Gas jet pumps and calibrated precsion orifices for sample dosage |
|
Outlet air via active carbon filter |
|
4 |
|
16 |
|
5 min |
|
115 l/min, oil-free |
|
22 (1:4)
- 216
(1:65,536) |
|
Factor 2 |
|
< 5% |
|
< 0.1 sec |
|
High concentrations: 1-2 liter Low concentrations: 6-8 liter |
